Ø20m (65ft) Insulated Glass Dome F6

Glass Dome – Ø20m (65ft) Structure - Insulated Glass Units

Product Overview

A stunning 20-meter (65-feet) diameter glass dome designed with precision and durability in mind. Ideal for use as a greenhouse, event space, or architectural feature.

Specifications

• Diameter: 20 m (65 ft)
• Height: 10,4 m (11 ft)
• Structure Type: Icosahedron F6
• Interior Floor Area: 290 m² (3121 sq ft)

Delivery Options

• EU: Door-to-door truck delivery
• Outside EU:
  • Truck delivery
  • Sea freight to port terminal
  • Air cargo to airport terminal
• Customs clearance not included for deliveries outside the EU
• Ships from: Vilnius, Lithuania (EU)
• Shipping: Calculated at checkout

Read our full Shipping Policy ›

What’s Included

• Step-by-step DIY assembly instructions
• T-STAR steel galvanized connectors set. Galvanizing min 20 mkr
• T-STAR steel galvanized support brackets. Galvanizing min 20 mkr
• T-profile galvanized steel struts set. Galvanizing min 20 mkr
• Nuts covers set, RAL7040
• Stainless steel A2 bolts, nuts and washers

• Aluminum profile struts and rubbers set. For IGU mechanical fixing.
• Stainless steel screw for IGU fixing, aluminum mounting bracket, IGU gaps insulation.
• Insulated glass units triangles Blue color: 8 ESG HST-24Ch-66.2LowE ESG HST VSG. 8 mm Planibel Azur Thermally toughened - 24 mm Argon 90% - Stratobel 66.2 (6 mm iplus 1.1T pos.3 + 0.76 mm PVB Clear + 6 mm Planibel Clearlite) Thermally toughened , UV resistant silicone RAL 7040. Figured tempered safety glass, safety laminate inner glass. Mechanical hidden fixing
• Insulated glass units triangles Extra Clear 8ESG HST VSG-24AL-66.2LowE ESG HST VSG, UV resistant silicone RAL7040, Figured tempered safety glass, safety laminate inner glass. Mechanical hidden fixing
• Insulated glass units triangles Opaque RAL7040 8ESG HST VSG-24AL-66.2LowE ESG HST VSG, UV resistant silicone RAL7040, Figured tempered safety glass, safety laminate inner glass. Mechanical hidden fixing
• Structural silicone one component DowSil 791, RAL 7040
• Entrance frame. Steel door frame cladding for door 1000x2100mm. Door and finishing around door not included
• Entrance frame.Steel door frame cladding for door 1800x2100mm. Door and finishing around door not included
• Automatic operational glass window 230V. Wiring and control panel not included.
• Maintenance loops M12 8 units. Stainless steel rod (riser)

Video

Warranty & Returns

• 5-year manufacturer’s warranty (covers manufacturing defects only)
• Not covered: misuse or damage from extreme weather conditions
• Returns: Not accepted
